ARDF
CSN003
1
One-pass duplex scanning ADF
1
CVA056
1. Sensors
1. Adjust the original guide to the original size.
2. Place the aligned originals squarely face up in the ADF.
Do not stack originals beyond the limit mark.
The first page should be on the top.
• ARDF
CSN004
1
2
2
• One-pass duplex scanning ADF
Placing Originals
61
