Thick Paper
This section gives you various details about and recommendations concerning thick paper.
When loading thick paper of 127.5–256.0 g/m
2
(47.0 lb. Bond–141.0 lb. Index) in Trays 1–3,
127.5–216.0 g/m
2
(47.0 lb. Bond–79.9 lb. Cover) in the LCT, or 127.5–300.0 g/m
2
(47.0 lb.
Bond–165.0 lb. Index) in the bypass tray or wide LCT, follow the recommendations below to prevent
misfeeds and loss of image quality.
• When loading thick paper in Trays 1–3, be sure to load at least 20 sheets. Also, be sure to
position the side fences flush against the paper stack.
• Jams and misfeeds can occur when printing on thick smooth paper. To prevent such problems, be
sure to fan smooth paper thoroughly before loading them. If paper continues to become jammed or
feed in together even after they are fanned, load them one by one from the bypass tray.
• When loading thick paper, set the paper direction according to its grain, as shown in the following
diagram:
Direction of paper
grain
Tray 1, LCT Trays 2–3 Bypass tray, wide LCT
Not supported
• Select [Thick Paper 1], [Thick Paper 2], [Thick Paper 3], or [Thick Paper 4] as the paper thickness
for the tray in [Tray Paper Settings].
• Even if thick paper is loaded as described above, normal operations and print quality might still not
be possible, depending on the paper type.
• Prints might have prominent vertical creases.
• Prints might be noticeably curled. Flatten out prints if they are creased or curled.
Envelopes
This section gives you various details about and recommendations concerning envelopes.
Recommended Paper Sizes and Types
159
