Ricoh Pro C7100

2. Set the end fence.
2
2
2
DER070
1
1. End fence
2. Extender
To remove the end fence, slide it to the right by pressing the stopper down.
CWW312
3. Press the elevator switch on the multi bypass tray (Tray A).
DER072
1
1
1. Elevator switch
The lamp of the elevator switch is blinking while the tray is going up, and keeps lit when it stops.
Press the elevator switch to move down the tray if you want to either add paper or remove jammed
ones.
Loading Paper
87
