4. Alert Indicator
This indicator lights up red when the machine runs out of paper or consumables, when the paper settings do
not match the settings specified by the driver, or when other errors occur.
5. Stop Fences
Raise this fence to prevent paper from falling off.
6. Front Cover
Open this cover to replace consumables or clear a paper jam.
7. Bypass Tray
This tray can hold one sheet of plain paper.
8. Tray 1
This tray can hold up to 150 sheets of plain paper.
9. Power Switch
Use this switch to turn the power on or off.
10. Power Connector
Connect the power cord to the machine here. Insert the other end of the cable into a nearby wall outlet.
11. Rear Cover
Open this cover to deliver sheets face up or remove jammed paper.
12. USB Port
Use this port to connect the machine to a computer using a USB cable.
13. Ethernet Port
Use this port to connect the machine to network using an Ethernet cable.
14. Tray Cover
Attach this cover when you extend the tray.
Interior
