CTT094
Extending Tray 1 to load paper
1. Pull Tray 1 out slowly, and then remove it using both hands.
2. Release the extender locks on both sides of the tray, and then pull out the extender.
CTT077
Make sure the extender's inner surface and the scale are aligned.
You can adjust the length of the extender in three steps. When using A4 or Letter size paper, adjust
the length to the position indicated by the mark " " in the tray.
3. Pull out the extender and lock it.
CTT076
4. Follow Steps 2 to 6 in "Loading Paper into Tray 1".
Loading Paper
27
