Removing Jammed Paper from Tray 1
1. Pull Tray 1 halfway out, and check for jammed paper. If there is jammed paper, remove it
carefully.
CTT030
2.
Carefully slide Tray 1 back in until it stops.
3. Open the front cover, and then carefully lower it.
CTT054
4. Carefully pull out the print cartridge horizontally, holding its center.
CTT045
• Do not shake the removed print cartridge. Doing so can cause remaining toner to leak.
• Place the print cartridge on paper or similar material to avoid dirtying your workspace.
6. Troubleshooting
60
