Ricoh SP 330DN Field Service Manual

2.Installation
9
 When disconnecting the power cord from the wall outlet, always pull the plug, not the cord.
Pulling the cord can damage the power cord. Use of damaged power cords could result in fire
or electric shock.
 The printer weighs approximately 17.5 kg (38.6 lb.). When moving the printer, use the inset
grips on both sides, and lift slowly. The printer will break or cause injury if dropped.
 When moving the printer after use, do not take out the toner bottle or the waste toner bottle, to
prevent toner spill inside the printer.
 Do not hold the control panel while moving the printer. Doing so may damage the control
panel, cause a malfunction, or result in injury.
Be careful when moving the printer. Take the following precautions:
 Turn off the main power.
 Close all covers and trays, including the front cover and bypass tray.
 If optional paper feed units are attached, remove them from the printer and move them
separately.
 Be sure to place the printer on a smooth and stable place.
 Keep the printer level and carry it carefully, taking care not to shake or tilt it. Rough handling
may cause a malfunction or damage the hard disk or memory, resulting in loss of stored files.
 Protect the printer from strong shocks. Impact can damage the hard disk and cause stored
files to be lost. As a precautionary measure, files should be copied to another computer.
1. Be sure to check the following:
The power switch is turned off.
The power cord is unplugged from the wall outlet.
The interface cable is unplugged from the printer.
2. Lift the printer by using the inset grips on both sides of the printer, and then move it horizontally to
the place where you want to install it.
 Be sure to move the printer horizontally. To prevent toner from scattering, move the printer
slowly.

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
