Using Smart Organizing Monitor
The state and status information of the machine can be checked using Smart Organizing Monitor.
Displaying the Smart Organizing Monitor Dialog
1. On the [Start] menu, click [SP 330_3710_Series_Software Utilities].
2. Click [Smart Organizing Monitor for SP 330 3710 Series].
3. If the machine you are using is not selected, click [Connect Printer], and then do one of the
following:
• Select the machine's model.
• Enter the IP address of the machine manually.
• Click [Search Network Printer] to search the machine via the network.
4. Click [OK].
Checking the Status Information
1
2
3
4
5
DYG347
1. Image area
Displays the status of this machine with an icon.
