Print Output Functions
You can specify the form of print outputs according to your purposes. This section briefly describes some
of the settings that you can specify.
Printing multiple sets of a document
You can print multiple sets of the same document.
Collating the output in document batches
You can print complete sets of a multiple-page document one set at a time (P1, P2, P1, P2 ...). If this
function is not used when printing multiple sets, prints will be output in page batches (P1, P1, P2,
P2 ...). This function is useful when, for example, making presentation materials.
Changing orientation or rotating the image
You can change the orientation of an image to portrait or landscape. You can also rotate the
image by 180 degrees. Use rotation to prevent an image from being printed upside down when
using paper with a predefined top and bottom (such as letterhead paper).
Printing multiple pages per sheet
You can print multiple pages onto one sheet of paper.
When using this function, a suitable reduction ratio is selected automatically based on the paper
size and the number of pages you want to fit on each sheet.
Printing on both sides of paper (duplex printing)
You can print on both sides of paper.
Reducing or enlarging the document
You can reduce or enlarge documents by a specific ratio, from 25% to 400% in 1% increments.
You can also reduce or enlarge documents automatically to fit a specific paper size. This function is
useful, for example, when printing Web pages.
If the [Enable Large Papers] option is selected, A3/11 × 17/B4/8K documents can be scaled to
a size that the machine supports, so that it can then be printed out.
Not printing of blank pages
If a print job contains blank pages, they can be prevented from being printed.
Note that this setting has higher priority than [Blank Page Print] under printer feature settings of the
control panel.
Printing with a cover page
You can add a cover page to the print job.
You can select to leave the cover page blank, or print the first page of the document on the cover
page. If a cover page is inserted into a duplex job, you can print on its back side also.
Paper for the cover page can either be the same as or different from the remaining pages.
3. Printing Documents
68

Table of Contents

Other manuals for Ricoh SP 3710DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 3710DN and is the answer not in the manual?

Ricoh SP 3710DN Specifications

General IconGeneral
ColorNo
Duplex printing-
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)7.5 s
Print speed (black, normal quality, A4/US Letter)32 ppm
Printer fontsPCL, PostScript
Printing colorsBlack
Maximum duty cycle- pages per month
Page description languagesPCL 5e, PCL 6, PostScript 3
Total input capacity300 sheets
Total output capacity125 sheets
Maximum input capacity550 sheets
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.72 W
Power consumption (printing)- W
Sustainability complianceYes
Sustainability certificatesENERGY STAR
Sound pressure level (printing)- dB
Product colorBlack, White
Market positioningHome & office
USB connectorUSB Type-B
USB 2.0 ports quantity1
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology10/100Base-T(X)
Server operating systems supportedWindows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supportedWindows 10, Windows 7, Windows 8.1
Included cartridge capacity (black)7000 pages
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height262 mm
