Removing jammed paper from Tray 1
If "Internal Misfeed", "Misfeed: Tray 1", or "Misfeed: Tray 2" appears on the display, follow the
procedure below to remove it.
The following example explains the removing procedure for the standard paper tray (Tray 1).
The same procedure applies to remove jammed paper from Tray 2.
1. Pull tray 1 halfway out, and check for jammed paper. If there is jammed paper, remove it
carefully.
2. Carefully slide tray 1 back in until it stops.
3. If paper is loaded in the bypass tray, remove the paper.
4. Close the bypass tray.
5. Push the side button to open the front cover, and then carefully lower it.
7. Troubleshooting
148
