When closing the front cover, push the upper area of the cover firmly. After closing the cover,
check that the error is cleared.
Removing jammed paper from the bypass tray
If "Misfeed: BypassTray" appears on the display, follow the procedure below to remove it.
1. If paper is jammed in the bypass tray input area, remove the jammed paper carefully.
DYG293
2. Close the bypass tray.
3. Push the side button to open the front cover, and then carefully lower it.
DYG268
7. Troubleshooting
150
