Ricoh SP 3710DN - Page 156

6. Close the rear cover.
DYG256
7. Pull tray 1 halfway out, and check for jammed paper. If there is jammed paper, remove it
carefully.
DYG289
8. Pull tray 1 out completely with both hands.
DYG305
Place the tray on a flat surface.
9. Push the lever.
Pushing the lever lowers the duplex transport unit.
7. Troubleshooting
154
