3. Pull up the fusing unit levers.
DAC071
4. Using both hands, carefully push up the front cover until it closes.
DAC062
When closing the front cover, push the upper area of the cover firmly. After closing the cover,
check that the error is cleared.
If paper jams inside a tray
If paper jams in Tray 1 or 2, follow the procedure below to remove it.
1. Pull the front cover open lever and then carefully lower the front cover.
2
1
DAC061
10. Troubleshooting
298
