11. Enter the encryption key using the number keys, and then press [Connect].
If you selected [Shared Key] or [Open System] in Step 9, it is necessary to enter the ID. The ID is
used for identifying the encryption key. You can register four encryption keys (ID 1 to 4). Use the
[ ] or [ ] key to switch between the encryption key and ID settings.
12. Press [Yes].
After connecting to the network, the Wi-Fi screen is displayed.
13. Press the [ ] or [ ] key to select [Wi-Fi Status], and then press the [OK] key.
When "Connected" is displayed, the connection has been established.
When "Disconnected" is displayed, the connection has not been established. Start again from the
beginning.
Ad Hoc mode
This section explains how to connect directly to devices equipped with a wireless LAN, such as
computers on a peer-to-peer network.
In Ad Hoc network, every device must be manually assigned an IP address for TCP/IP if there is no
DHCP server.
In Ad Hoc mode, only Open System or WEP encryption is supported. WPA2-PSK and Mix Mode
WPA2/WPA authentication methods are not supported.
1. Turn on the machine.
2. Press the [User Tools] key.
3. Press the [ ] or [ ] key to select [Network Settings], and then press the [OK] key.
4. If you are requested to enter a password, enter the password using the number keys,
and then press the [OK] key.
5. Press the [ ] or [ ] key to select [Wi-Fi Configuration], and then press the [OK] key.
6. Press the [ ] or [ ] key to select [Setup Wizard], and then press the [OK] key.
7. Press the [ ] or [ ] key to select [Ad-Hoc], and then press [Next].
8. Press the [ ] or [ ] key to select a communication channel, and then press [Next].
Select a channel that corresponds to the device that you are going to connect with.
9. Press the [ ] or [ ] key to select the destination device name (IBSS), and then press
[Next].
If you cannot find the destination, check that the device is turned on.
When entering the device name, select [Input SSID], and then press [Next]. The SSID entry screen
appears. Enter the device name using the number keys, and then press [Next].
10. Press the [ ] or [ ] key to select the authentication method, and then press [Next].
1. Getting Started
48

Table of Contents

Other manuals for Ricoh SP C252SF

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP C252SF and is the answer not in the manual?

Ricoh SP C252SF Specifications

General IconGeneral
Digital sender-
Maximum duty cycle65000 pages per month
Page description languagesPCL 5c, PCL 6, PostScript 3
Duplex printingYes
Print technologyLaser
Maximum resolution2400 x 600 DPI
Time to first page (black, normal)14 s
Print speed (black, normal quality, A4/US Letter)20 ppm
Processor familyIntel® Celeron® M
Processor frequency400 MHz
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1300 W
Power consumption (average operating)- W
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies99 copies
FaxingColor faxing
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)200 x 100 DPI
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Total input capacity251 sheets
Total output capacity150 sheets
Maximum input capacity751 sheets
Standard interfacesEthernet, USB 2.0, Wireless LAN
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Ethernet LAN data rates10, 100 Mbit/s
Scan toE-mail, File
Scan driversTWAIN
Scanner typeADF scanner
Image formats supportedJPG
Document formats supportedPDF
Optical scanning resolution1200 x 1200 DPI
Product colorBlack, White
Market positioningBusiness
Weight and Dimensions IconWeight and Dimensions
Depth493 mm
Width420 mm
Height460 mm
