2. Slide both sides of the paper guide outward, and then load paper print side up until it
stops.
3. Slide both sides of the paper guide outward, and then load paper print side down until it
stops.
1
1
2
DSE126
4. Adjust both sides of the paper guide to match the paper width.
DSE127
• When using the bypass tray, it is recommended that you set the paper direction to .
• Before loading Postcard or 148 × 200 mm paper, straighten any curls within 2 mm (0.1 inch)
upward and 0 mm (0 inches) downward on the tray.
• Letterhead paper must be loaded in a specific orientation. For details, see page 49 "Loading
Orientation-Fixed Paper or Two-Sided Paper".
• You can load envelopes into the bypass tray. Envelopes must be loaded in a specific orientation.
For details, see page 51 "Loading Envelopes".
2. Loading Paper
48

Ricoh SP C352dn Specifications

General

Color	Yes
Print technology	LED
Duplex printing mode	Manual
Time to first page (black, normal)	6 s
Time to first page (color, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Control type	Touch
Product color	White
Display diagonal	4.3 \
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1200 W
Power consumption (ready)	40.2 W
Power consumption (printing)	- W
Energy Star Typical Electricity Consumption (TEC)	1.16 kWh/week
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PDF, PostScript 3
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Total input capacity	- sheets
Maximum input capacity	2100 sheets
Total number of input trays	-
Paper tray media types	Bond paper, Card stock, Coated paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	56 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5, B6
Maximum ISO A-series paper size	A4
Optional connectivity	Parallel, Wireless LAN
USB 2.0 ports quantity	2
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Sound pressure level (printing)	- dB
Cables included	AC

Weight and Dimensions

Depth	515 mm
Width	400 mm
Height	387 mm
