Timer Reset {CS Menu}
IF changing timer values while the output is already ON.
ON ‘Timer Mode’ timers will reset/begin after exiting from the menu.
OFF ‘Timer Mode’ timers will begin when the output is next turned ON.
Notes:
Timer begins counting after enabling the RD60xx output.
(If the output was already enabled, the timer is already running. )
e.g.
If you:
Turn on the output, and wait more than 1 min.
Enter the menu and set the ‘Timer Reset’ to 1 min
Exit from menu (apply setting)
Then:
Output will immediately turn OFF.
(Because 1 min. has already passed since the output was
turned ON.)
Enabling this option forces the timer to reset when the settings are applied.
V-SET (Set Voltage, in Volts)
Can Only be Enabled by Panel button “V-SET”
Value of the Voltage Setpoint, in Volts, for when the unit is in CV Mode. It also represents an
upper limit for Voltage when in CC Mode.
Rotate “Encoder” Knob to desired value.
Use “◄” or “►” to switch selected multiplier (cursor location).
OR
Enter the desired value using the Keypad.
UART Baudrate
➥Communication
Selectable Options: 9600 / 19200 / 38400 / 57600 / 115200
Only applies to the INTERNAL communication ‘UART Interface’.
(NOT the front panel USB)
IF ‘WIFI’ selected as ‘UART Interface’ setting:
Baud Rate is FIXED at 115200, regardless of value selected.
