CCP-1116 Commentary Control Panel – Quick Guide 1.2
Page 13
5.3 Commentary Audiopatch settings
Finally you have to adjust the internal audio routing of the Audio patches in the CCP-1116.
Up to Director Version 6.50 the audio in-and outputs of the Audio patches are used inside the CCP-
1116 as follows:
Audiopatch INPUT
CCP-1116 connector
Panel MIC
Standard panel gooseneck microphone
(only when the CCP-1116 is used as a pure intercom panel)
Headset A
Headset A Intercom (XLR 5pol. front side)
(only when the CCP-1116 is used as a pure intercom panel)
External MIC
LINE IN Input (XLR 3pol. rear side) only available in Speaker-Mode
Headset B
Headset B Intercom (XLR 5pol. front side)
(only when the CCP-1116 is used as a pure intercom panel)
AUDIO IN A
MIC A (XLR 3pol. front side)
The key “MIC MUTE A” take effect always on this input signal. Exclusive this signal
is routed hard wired to the XLR “AIR A OUT” and “AIR A+B OUT” analog outputs
and can be affected by the “ON AIR A” key.
AUDIO IN B
MIC B (XLR 3pol. front side)
The key “MIC MUTE B” takes effect always on this input signal. Exclusive this
signal is routed hard wired to the XLR “AIR B OUT” and “AIR A+B OUT” analog
outputs and can be affected by the “ON AIR B” key.
Matrix CH. 1
Audio channel 1 (Commentator A), Intercom coming from the matrix to the CCP-
1116
Matrix Ch. 2
Audio channel 2 (Commentator B), Intercom coming from the matrix to the CCP-
1116
Audiopatch OUTPUT
CCP-1116 connector
Speaker
Standard panel loudspeaker
Headset A
Headset A Intercom (XLR 5pol. front side)
External Out
Ext. Speaker (XLR 3pol. rear side)
Headset B
Headset B Intercom (XLR 5pol. front side)
AUDIO OUT A
PHONES A (Stereo-jack, front side)
AUDIO OUT B
PHONES B (Stereo-jack front side)
Matrix CH. 1
Audio channel 1 (Commentator A), Intercom going from the CCP-1116 to the
matrix
Matrix Ch. 2
Audio channel 2 (Commentator B), Intercom going from the CCP-1116 to the
matrix
