CCP-1116 Commentary Control Panel – Quick Guide 1.2
Page 18
7 SPECIFICATIONS
POWER
Internal Power Supply
90 – 253V AC (47-63Hz) max 35VA
Power supply redundancy via external power supply
10 – 16V DC via XLR4
MICROPHONE INPUT (MIC A IN, MIC B IN)
Coupling
Transformer
Phantom Power
48V
Gain Range
10 – 70dB
Gain Switch
-20dB
Maximum Input Level
+6dBu
High-Pass Filter
100Hz
Limiter
@ +6dBu
Input Noise Voltage
-126dBu @200Ω Source
CMRR
>60dB @ 1kHz
AUDIO LINE INPUT (AUX 1 IN, AUX 2 IN)
Coupling
Transformer
Impedance
≥10kΩ
Maximum Input Level
+18dBu
Nominal Input Level
+6dBu
Input Noise Voltage
-73dBu (20Hz-22kHz)
THD+N
<0,1% (+18dBu, 1kHz)
CMRR
>60dB @ 1kHz
AUDIO LINE INPUT (LINE IN)
Coupling
Transformer
Impedance
≥10kΩ
Input Level
10 – +18dBu
Nominal Input Level
-+6dBu
Input Noise Voltage
-73dBu (20Hz-22kHz)
THD+N
<0,2% (<0,05% @ 1kHz)
SNR
>91dB
AUDIO LINE OUTPUT (DIRECT OUT A, DIRECT OUT B, AIR A OUT, AIR B OUT, AIR A+B OUT)
Coupling
Transformer
Impedance
≤50Ω
Maximum Output Level
+18dBu
Nominal Ouput Level
-+6dBu
Output Noise Voltage
-100dBu (20Hz-22kHz)
THD+N
<0,02% (+6dBu @ 1kHz)
<0,2% (+6dBu @ 40Hz)
HEADPHONE (PHONE A, PHONE B)
Load
>25Ω
Maximum Output Level
+25dBu
Output Noise Voltage
-75dBu
THD+N
<0,05% (+18dBu @ 1kHz)
