4.1 Stream consumer
The tab Stream consumer allows configuring up to six streams to be received at the NSA-002A. Accepted are
Ravenna streams, Dante-AES67 streams and manual configured streams via SDP.
Each of the six XLR audio channels are configured in one "Channel". Hence, each interface is able to receive six
different streams or a stream consisting of six channels is distributed to the six interfaces.
figure 18: NSA-002A web interface "Stream consumer"
Name
The name is entered if a Ravenna- or Dante-Stream is selected by discovery. The name
can be assigned freely.
Source Stream
Table of all available Ravenna- or Dante-AES67-Streams.
Channel number
If a stream consists of multiple channels, this selection determines the channel that is
output on the respective XLR output.
Show Advanced
settings
Manuel path of the Bonjour streams.
Manual SDP
Opens a dialog to import a SDP of a 3rd-Party-Sender (i.e. Artist).
Status
Each channel shows its status next to the channel number:
IDLE
No stream is configured.
WAITING
Stream configured but not received.
RECEIVING
MULTICAST
SYNTONIZED
Configured multicast stream is received
(without PTP synchronization).
RECEIVING
UNICAST
SYNTONIZED
Configured unicast stream is received
(without PTP synchronization).
RECEIVING
MULTICAST
Configured multicast stream is received.
RECEIVING
UNICAST
Configured unicast stream is received.
RECEIVING
NO_SYNC
Configured stream is received but the PTP synchronization is not
valid.
RECEIVING TIME
STAMP WARNING
Configured stream is received but the received packets differ more
than one ms from the expected time.
DISABLED
The receiver is disabled to save resources.
