NSA-002A User Manual A00

4.2 Stream provider

The tab Stream provide allows configuring the stream to be transmitted.

The stream contains six channels with the signals of the analog XLR inputs 1-6.

figure 19: NSA-002A web interface "Stream provider"

Stream name

Name of the streams.

Activate

Activates the respective stream (after clicking the "Apply all" button).

SDP

Shows the session descriptions.

Status

Shows the state of the respective channel (see Status in chapter 'Stream consumer').

Multicast

Address, Port

Fields for manual configuration of the multicast addresses and ports.

Use automatic

configuration

If enabled, the multicast addresses of the streams are numbered consecutively in the the

NSAs ZeroConf address range.
