4.4 Advanced
The tab Advanced allows configuring PTP, SIP and SAP configurations.
figure 21: NSA-002A web interface "Advanced"
PTP
State
Shows the PTP-state, grandmaster and the current
clock offset.
Domain
Allows entering a PTP-domain.
Prefered master
Sets the PTP-priority 1 and 2 to "20".
Slave only
Blocks the device to be used as synchronization
master.
SIP configuration
Allows setting the SIP username if SIP connections are desired.
SAP configuration
SAP browsing enabled
Shows also Dante-AES67-Streams in the Stream
consumer tab.
Multicast Adress, Port, Session
Timeout
Specific configuration of the SAP-announcements.
