2.2 Status LEDs
Device mode
(top)
blue
Bolero mode (plug-and-play mode for Bolero wireless intercom
systems)
violet
Manual mode
State
(middle)
Bolero
plug & play mode
green
Connection OK
green blinking
· Synchronization errors. (This may happen
during the first 5 min.)
· Check PTP settings.
· Audio glitches may happen.
red
Antenna not connected or not configured in
Bolero web server.
orange
All other cases.
Manual mode
green
Connection OK or idle (not configured).
green blinking
Connection configured but no data
communication.
red
Connection configured but mismatch
between sender and receiver.
orange
· Synchronization errors. (This may happen
during the first 5 min.)
· Check PTP settings.
· Audio glitches may happen.
off
All other cases.
PTP Status
(bottom)
green
PTP slave, PTP offset <1 µs
green blinking
PTP master
orange
PTP slave, PTP offset 1 ... 100 µs
orange blinking
PTP listening, Slave mode only
red
· Error
· PTP offset >100 µs
Network
(left)
off
no connection
green
Ethernet connection ok
Activity
(right)
off
no data transmission
green / yellow
blinking while data transmission
