NSA-002A User Manual A00
5.2 Technical Specifications
Type
NSA-002A (Network Stream Adapter)
Amount of analog breakouts
6x input, 6x output
Analog audio line input/output
balanced
Nom. input/output level
+6 dBu
Max. input/output level
+24 dBu
Input impedance
10 kΩ
Output impedance
<200 Ω
Min. load Impedance
2 kΩ
Frequency response
20 Hz ... 20 kHz
-0.5 dB
Signal to noise ratio (SNR)
>100 dB
@ +24 dBu
Crosstalk
<-110 dB
@ 1 kHz
adjacent channels
Total harmonic distortion (THD&N)
typ. 0.008 %
@ +6 dBu
Resolution
24 bit
GPI input
3x Galvanically isolated opto-coupler inputs
Isolation voltage
100 VDC
Max. voltage
30 VDC
Input current
5 mA @ 5 VDC
Switching threshold
off: <0.8 VDC, on: >2.0 VDC
GPO output
3x Galvanically isolated solid-state relay outputs
Isolation voltage
100 VDC
Max. voltage
30 VDC
Max. current
100 mA
Power supply
Mains
100 ... 240 V, 50/60 Hz,
max. 0.6 A inrush current
PoE IEEE 802.3af type 1
42 ... 57 V
Power consumption
Mains
<25 W / <85 BTU/hr
PoE class 3
<12.95 W / <44.19 BTU/hr
Dimensions
(with bumpers)
Width
218 mm / 8.6" (242 mm / 9.5")
Height
45 mm / 1.8" (65 mm / 2.6")
Depth
276 mm / 10.9" (293 mm / 11.5")
Weight
(with bumpers)
1770 g (2250 g)
Operating Environment
Temperature
0° … +50°C
Humidity
20 % ... 90 % rel. (non-condensing)
