Riello UPS CSS SENTINEL TOWER CAM 3 - Display Panel View

- 8 -
DISPLAY PANEL VIEW
“ON” button Input phase indicator
“SEL1” button Measurement display area
“SEL2” button Timer
“STAND-BY” button Battery charge indicator
Regular operation Configuration area
Mains operation Maintenance request
Battery operation Load level indicator
Load powered by bypass Parallel mode indicator
Stand-by / alarm EnergyShare
