Riello Array AR 800 - APPENDIX L - FLOWCHARTS

70
SHUTDOWN
70
APPENDIX
APPENDIX
Add Boiler
function
Remove
Boiler
function
* *
Delay period
for starting new
boiler is 0?
Delay period for
removing boiler
is 0?
Are we allowed
to add another
dependent?
Are we allowed to
remove another
dependent?
YES
YES
YES
YES
Add dependent from the
cascade demand
Remove dependent to the
cascade demand
Reload delay time
Reload delay time
Update
demand flags
Update
demand flags
NO
NO
NO
NO
* *
BOILER CASCADE: ADD/REMOVE BOILER
