LPG KIT
There is a special kit available that, when mounted on the combustion head, enables burners designed to
run off natural gas to burn LPG instead. Refer to the instructions supplied with the “LPG kit” for installation.
The kit must be installed in conformity with laws and local regulations.
ALTERNATIVE COMBUSTION HEAD KIT
The kit can be used to avoid combustion instability that might be encountered in special applications.
The kit must be installed in conformity with laws and local regulations.
SEAL CONTROL KIT
There is a special kit available that can be used to check the seal of the gas train’s valve.
This kit cannot be used for gas trains with valve model MULTIBLOC MBDLE 055.
The kit must be installed in conformity with laws and local regulations.
2. TECHNICAL DATA
2.1 TECHNICAL DATA
(1)
Reference conditions: Temperature 20°C - Barometric pressure 1013 mbar – Altitude 0 m above sea level.
Model BS2F BS3F BS4F
Burner delivery
(1)
Thermal power
(1)
35 − 91 kW
30.1 − 78.2 Mcal/h
65 − 200 kW
55.9 − 172 Mcal/h
110 − 250 kW
94.6 − 215 Mcal/h
Fuel Net heat value: 8 − 12 kWh/Nm
3
= 7000 − 10.340 kcal/Nm
3
Pressure: min. 20 mbar – max. 65 mbar
Main power supply Single phase, 50/60Hz ~ 220/230V ± 10%
Fan motor 50 Hz
0.7 A absorbed
2835 g/min.
298 rad/s
60 Hz
0,9 A absorbed
3245 rpm.
341 rad/s
50 Hz
1.6 A absorbed
2790 rpm.
293 rad/s
60 Hz
2.2 A absorbed
3070 rpm.
322 rad/s
50 Hz
1.9 A absorbed
2740 rpm.
288 rad/s
60 Hz
2.7 A absorbed
2845 rpm.
299 rad/s
Capacitor 4 μF 6.3 μF 8 μF
Ignition transformer Primary 230V / 0,2A - Secondary 8 kV / 12 mA
Absorbed electrical power 0.155 kW 0.20 kW 0.355 kW 0.485 kW 0.42 kW 0.60 kW
Model BS2F-GPL BS3F-GPL BS4F-GPL
Burner delivery
(1)
Thermal power
(1)
35 − 91 kW
30.1 − 78,2 Mcal/h
65 − 200 kW
55.9 − 172 Mcal/h
110 − 250 kW
94.6 − 215 Mcal/h
Fuel Net heat value: 24 − 34 kWh/Nm
3
= 21.000 − 29.000 kcal/Nm
3
Pressure: min. 20 mbar – max. 100 mbar
Main power supply Single phase, 50/60Hz ~ 220/230V ± 10%
Fan motor 50 Hz
0.7 A absorbed
2835 rpm.
298 rad/s
60 Hz
0.9 A absorbed
3245 rpm.
341 rad/s
50 Hz
1.6 A absorbed
2790 rpm.
293 rad/s
60 Hz
2.2 A absorbed
3070 rpm.
322 rad/s
50 Hz
1.9 A absorbed
2740 rpm.
288 rad/s
60 Hz
2.7 A absorbed
2845 rpm.
299 rad/s
Capacitor 4 μF 6.3 μF 8 μF
Ignition transformer Primary 230V / 0,2A - Secondary 8 kV / 12 mA
Absorbed electrical power 0.155 kW 0.20 kW 0.355 kW 0.485 kW 0.42 kW 0.60 kW
