Installation
5.6 Boiler fixing
 Put on the flange 1)(Fig. 6) the screw and two nuts.
 Fix the flange 1)(Fig. 7) to the boiler door 4) using screws 2)
and (if necessary) the nuts 3) interposing the insulating gas-
ket 5).
E9095
1
Fig. 6
Provide an adequate lifting system of the burner.
WARNING
The seal between burner and boiler must be
airtight.
5
1
E9094
2
4
3
Fig. 7
