Riello RS 100/E - Maximum dimensions

20068428
8
GB
Technical description of the burner
4.3 Burner categories
Tab. B
4.4 Technical data
Tab. C
Tab. D
(1)
Reference conditions: Room temperature 20°C - Gas temperature 15°C - Barometric pressure 1013 mbar - Altitude 0 m above sea level.
(2)
Gas pressure on the pipe coupling test point 21)(Fig. 5 at page 14) with zero pressure in the combustion chamber and at maximum burner output.
(3)
Sound pressure measured in manufacturer's combustion laboratory, with burner operating on test boiler and at maximum rated output. The sound
power is measured with the “Free Field” method, as per EN 15036, and according to an “Accuracy: Category 3” measuring accuracy, as set out in
EN ISO 3746.
(4)
Blast tube: short-long.
Country of destination Gas category
BE I2E(R)
LV I2H
CY, MT I3B/P
BE I3P
LU, PL II2E3B/P
DE II2ELL3B/P
FR II2Er3P
AT, CH, CZ, DK, EE, FI, GR, HU, IS, IT, LT, NO, SE, SI, SK II2H3B/P
ES, GB, IE, PT II2H3P
NL II2L3B/P
Model RS 70/E RS 100/E RS 130/E
Output
(1)
Max. kW
Mcal/h
470 ÷ 930
404 ÷ 800
700 ÷ 1340
602 ÷ 1152
920 ÷ 1600
791 ÷ 1376
Min. kW
Mcal/h
150
129
150
129
240
206
Fuel Natural gas: G20 (methane gas) - G21 - G22 - G23 - G25
Gas pressure at max. output
(2)
-
Gas: G20/G25
mbar
12.9 / 19.2 11.4 / 17.0 9.1 / 13.6
Operation – Intermittent (min. 1 stop in 24 hours)
– Two progressive or modulating stages with kit (see ACCESSORIES)
Standard applications Boilers: water. steam. diathermic oil
Ambient temperature °C 0 - 40
Combustion air temperature °C max 60
Noise levels
(3)
Sound pressure
Sound power
dB(A)
75
86
77
88
78.5
89.5
Weight
(4)
kg 77 - 79 80 - 82 83 - 85
Model RS 190/E RS 250/E MZ
Output
(1)
Max. kW
Mcal/h
1279 ÷ 2290
1100 ÷ 1970
1250 ÷ 2650
1075 ÷ 2279
Min. kW
Mcal/h
470
405
600
516
Fuel Natural gas: G20 (methane gas) - G21 - G22 - G23 - G25
Gas pressure at max. output
(2)
-
Gas: G20/G25
mbar
14.9 / 22.2 19.4 / 28.9
Operation – Intermittent (min. 1 stop in 24 hours)
– Two progressive or modulating stages with kit (see ACCESSORIES)
Standard applications Boilers: water. steam. diathermic oil
Ambient temperature °C 0 - 40
Combustion air temperature °C max 60
Noise levels
(3)
Sound pressure
Sound power
dB(A)
83.1
94.1
83
94
Weight
(4)
kg 89 - 91 124 - 126
