Riello RS 100/E - CHECKS ON THE BURNER

20068428
48
GB
Start-up, calibration and operation of the burner
146
Baud Rate for Modbus
Values set:
0 = 9600
1 = 19200
1 - Modification 0 1 1 1 Service mode
147
Parity for Modbus
0 = none
1 = odd
2 = even
1 - Modification 0 2 1 0 Service mode
148
Selection of the burner operation during the interrup-
tion of the switch-over with the system of remote man-
agement.
Values set:
With modulating operation the settings of the values
are the following:
0...19.9 = burner switched off
20...100 = 20...100% modulation field of the burner.
With stage operation:
0 = burner off P1, P2, P3
No setting = no function in the event of communication
interruption
1 %
Modification /
zero setting
0% 100% 0.1% Not defined Service mode
161 Total number of errors 1 - Reading only 0 65535 1 0 Info mode
162 Hours of operation (that can be reset) 1 h Reset 0h 999999 h 1h 0h Info mode
163 Total hours of power supply to control box 1 h Reading only 0h 999999h 1h 0h Info mode
164 Total number of start-ups (that can be reset) 1 - Reset 0 999999 1 0 Info mode
166 Total number of start-ups 1 - Reading only 0 999999 1 0 Info mode
167
Volumetric delivery of fuel in the selected unit of meas-
urement (that can be reset)
1
m
3
, l,
ft
3
, gal
Reset 0 99999999 1 0 Info mode
200 CHECKS ON THE BURNER
201
Burner operation mode (fuel supply line, modulating/
stage, servomotors, etc.)
-- = not defined (eliminate curves)
1 = Gmod
2 = Gp1 mod
3 = Gp2 mod
4 = Lo mod
5 = Lo 2 stage
6 = Lo 3 stage
7 = Gmod pneu
8 = Gp1 mod pneu
9 = Gp2 mod pneu
10 = LoGp mod
11 = LoGp 2-stage
12 = Lo mod 2 fuel valves
13 = LoGp mod 2 fuel valves
14 = G mod pneu without actuator
15 = Gp1 mod pneu without actuator
16 = Gp2 mod pneu without actuator
17 = Lo 2-stage without actuator
18 = Lo 3-stage without actuator
19 = G mod only gas actuator
20 = Gp1 mod only gas actuator
21 = Gp2 mod only gas actuator
22 = Lo mod only oil actuator
1 -
Modify/set to
zero
1 22 1 Not defined Service mode
208
Stopping of the program
0 = deactivated
1 = pre-purging (Ph24)
2 = Ignition (Ph36)
3 = Interval 1 (Ph44)
4 = Interval 2 (Ph52)
1 - Modification 0 4 1 0 Service mode
210
Alarm as the pre-purging phase begins;
0 = Deactivated;
1 = Activated
1 - Modification 0 1 1 0 Service mode
211 Uphill train fan motor 1 s Modification 2s 60s 0.2s 2s Service mode
212 Maximum time to reach low flame 1 s Modification 0.2s 10 min 0.2s 45s Service mode
215
Maximum repeats of safety circuit
1 = No repetition
2...15 = Number of repetitions
16 = Constant repetitions
1 - Modification 1 16 1 16 Service mode
Parameter
No. ele-
ments
Unit of
measure
Modifica-
tion
Value range
Degree of
accuracy
Default
setting
Acces mode
No. Description Min. Max.
