Technical description of the burner
4.1 Burner designation
4.2 Models available
4 Technical description of the burner
Designation Voltage Start-up Code
RS 28 TC 1/230/50 Direct 3783302
RS 38 TC 1/230/50 Direct 3784402
RS 38 TL 1/230/50 Direct 3784403
RS 38 TC 3/230-400/50 Direct 3784502
RS 38 TL 3/230-400/50 Direct 3784503
RS 50 TC 3/230-400/50 Direct 3784702
RS 50 TL 3/230-400/50 Direct 3784703
Series: R
Size
Fuel: Natural gas
Oil
Gas oil / Methane
Adjustment:
Flame control system:
FS1
FS2
Standard (1 stop every 24 hours)
Continuous working (1 stop every 72 h)
Electrical supply of the system:
3/400/50
3/230/50
Voltage of auxiliaries:
230/50/60
110/50/60
R S 28 TC
Emission:
C1 or... Class 1 EN676
C02 or MZ Class 2 EN676
C03 or BLU Class 3 EN676
3/230/50 230/50/60
BASIC DESIGNATION
EXTENDED DESIGNATION
3N / 400V / 50Hz
3 / 230V / 50Hz
230V / 50-60Hz
110V / 50-60Hz
Heavy oil
E Electronic cam
EV Electronic cam and variable speed (with Inverter)
P Proportional air/gas valve
BP Two stage (light oil) / Proportional valve (gas)
M Mechanical cam
S
L
LS
N
Head:
TC Standard head
TL Extended head
