43
8.3.3. Headset
Apply the front brake and place the thumb
and forefinger of your other hand around the
upper headset bearing.
Move your E-Bike forward and backward.
If there is play in the bearing, you will notice
that the parts of the headset are shifting.
If this is the case, the headset bearing must
be readjusted by your authorized dealer.
Lift your E-Bike up at the front until the front wheel is in the air. Move the handlebar to the left
and the right. The steering must turn smoothly and without resistance. If the steering is sti to
any noticeable extent, the headset bearing must be repaired by your authorized dealer.
8.3.2.4. Brake pads
Check the thickness of the brake pads. When worn down to their minimum thickness, the brake
pads must be replaced by your authorized dealer.
The pad carrier of the disc brake pads must never touch the brake disc. For more information
on the minimum thickness, refer to the separately included instructions provided by the brake
manufacturer.
Minimum thickness of disc brake pads
Checking the headset play
Minimum thickness of rim brake pads
New brake pad
New
brake pad
Worn
brake pad
Worn brake pad
10/128 “ 2/128 “
