8.4.4. Torque Settings for E-Cargo Bikes
PART FITTING TORQUE ft.lb / Nm
Frame
Connection front/rear frame 4 x M10 screws 265–354 / 30–40
Connection front/rear frame 2 x M8 screws 177–221 / 20–25
Front fork
Steerer clamp above the headset 2 screws 106–124 / 12–14
Clamp for steering rod at right stanchion 4 x M5 screws 44–53 / 5–6
Steering linkage Front and rear steering linkage 2 x M6 screw and nut 80–106 / 9–12
Kickstand
Counter nuts M8 106–124 / 12–14
Eye bolts and M5 nuts for kickstand spring
44–53 / 5–6
PART FITTING TORQUE ft.lb / Nm
Clamp stem to steerer 4 clamping screws M6 62–80 / 7–9
Angle adjustment
2 front clamping screws M6 62–80 / 7–9
2 rear clamping screws M5 27–35 / 3–4
2 set screws at quick release levers 9 / 1
8.4.5. Torque Settings for adjustable Stems
