4.5.3. Data screen
In the SWR graph and R,X graph modes, press the F + 1 combination to display
various parameters at cursor:
4.5.4. Memory operation
In the SWR graph and R,X graph modes, you may choose to scan to memory
(the 6 key). There are 100 independent memory slots. Later, you may recall ( 9 ) the
plots from the specified memory.
Additionally, the F + 9 combination opens the editor of memory slot names.
4.6. Settings menu
The Settings menu (press the 0 key in the Main menu) contains various settings for the
analyzer. The first page contains the following commands:
2 – language selection;
3 – backlight on or off;
4 – sound on or off;
5 – battery type (NiMH or alkaline, to let the battery discharge indicator work
properly);
0 – go to the second page of settings which contains SWR and R,X display
options:
