Driver Configuration Guide (Windows 98/ME) 11
1. As a result of successful installation, you
will see four new serial ports in the Device
Manager (right-click My Computer on the
desktop, select Properties from the menu, then
select Device Manager tab in the System
Properties dialog. Open Ports (COM & LPT)
branch in the device tree.)
2. To view the RigExpert Standard serial port
assignment, please run the ListRE program
from Start – Programs – RigExpert Standard
– Show serial ports:
3. Write down the port numbers on a piece of
paper. For instance,
CAT port: COM3
PTT/CW port: COM4
SERIAL port: COM5
FSK port: COM6
These port numbers will be needed later to set
up your software.
4. Changing serial port numbers.
The serial port numbers are assigned automatically
during driver installation. If you need to change their
values, open Device Manager, right-click the USB
Serial Port (COMxx), then select Properties from the
menu. In the USB Serial Port (COMxx) Properties
dialog, activate Port Settings tab, then click Advanced
button.
In the newly-open Advanced Port Settings dialog,
select a new COM Port Number.
Click OK to apply new settings and close the Advanced
Port Settings dialog.
You will have to re-plug the RigExpert Standard device
for this change to take effect.
It is recommended for all four ports to uncheck the Serial
Enumerator check-box in the same window:
This will eliminate a case when Windows is trying to
find a mouse or other device on this port when you plug
in the RigExpert Standard.
