Rigol 2000 Series User Manual

Chapter 14 Store and Recall RIGOL
MSO2000A/DS2000A User’s Guide 14-19
Math Operation Setting (MATH->Operate)
Operate OFF
A+B
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 2 V
A-B
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 2 V
A×B
Source A CH1
Source B CH1
Vertical Invert OFF
Scale 2 U
A÷B
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 2 U
FFT
Source CH1
Window Function Rectangle
Display Split
Scale dB
Vertical Scale 20 dBV
Horizontal Scale 1.25 MHz/div
Sample Rate 50 MSa/s
Anti-Aliasing OFF
Logic Operation
Log.Formula AND
Source A CH1
Source B CH1
Invert OFF
