RIGOL Chapter 14 Store and Recall
14-20 MSO2000A/DS2000A User Guide
Vertical Scale 1 U
Threshold A 0 V
Threshold B 0 V
Advanced Operation
Expression OFF
Expression CH1+CH2
Vertical Scale 2 V
Invert OFF
Logic Analyzer (LA)
[2]
Channel/Group D0
On/Off D7-D0: OFF; D15-D8: OFF
Waveform Size M
Reorder D0-D15
Threshold Type TTL
Digital Bus BUS1
BUS Status OFF
Channel Selection D7-D0
Endian Normal
Reference Clock None
Slope Rising Edge
Display Type Data
Format Hex
Jitter Rejection ON
Jitter Time 5.00 ns
Protocol Decoding (Decode 1, Decode 2)
Decoding Type Parallel
Bus Status OFF
Format Hex
Offset 0
Threshold 0
Parallel
Clock Channel CH1
Slope Rising Edge
Bus Bits 8
