RIGOL Chapter 3 Remote Control
3-4 DL3000 User’s Guide
3. Search for the device resource
Start up Ultra Sigma and the software will automatically search for the resource
currently connected to the PC. You can also click
to search for the
resource.
4. View the device resource
The searched instrument resource will be under the directory of "RIGOL Online
Resource", with the model of the instrument and the USB information being
displayed.
5. Control the instrument remotely
Right-click the resource name "DL3031A
(USB0::0x1AB1::0x0E11::DL3000A000001::INSTR)", and select "SCPI Panel
Control" to open the remote command control panel, as shown in the following
figure. Then you can send commands and read data through the panel.
