Chapter 1 Quick Start RIGOL
DL3000 User’s Guide 1-9
10. Menu Keys
You can press the specified menu key to execute the corresponding operation
displayed at the bottom of the interface on the screen.
11. USB Host
(1) The instrument is regarded as the "master device". You can use the data line
to connect it to the USB storage device (e.g. U-disk) to realize external
storage or recalling.
(2) Use the USB-GPIB interface converter to extend the GPIB interface for the
load, and then use the GPIB cable to connect the load to the PC to realize
remote control.
12. Power Key
Turn on or off the instrument.
