Chapter 2 Front Panel Operations RIGOL
DL3000 User’s Guide 2-41
(2) Enter Value
 In CC mode, the set value is for current, and its default unit is A.
 In CV mode, the set value is for voltage, and its default unit is V.
 In CR mode, the set value is for resistance, and its default unit is Ω.
 In CP mode, the set value is for power, and its default unit is W.
a) In the main interface, press the Up/Down arrow key to switch the
parameter focus to the "Value" line.
b) Enter a value by using the numeric keys. For setting methods, refer to
the descriptions in "Parameter Setting Method".
Note: If the parameter focus is on the "Value" line, press the Left/Right
arrow key or rotate the knob to set the value for the adjacent step.
(3) Set Duration
The default unit for duration is s. Its range is 0.00005 s to 3600 s.
 Press the Up/Down arrow key to switch the parameter focus to the
"Duration" line.
 Enter a value by using the numeric keys. For setting methods, refer to
the descriptions in "Parameter Setting Method".
Note: When the current parameter focus is on the "Duration" line, press
the Left/Right arrow key or rotate the knob to switch the parameter focus to
the duration for the adjacent step.
(4) Set Slew (only available in CC mode)
The default unit for the slew rate is A/μs.
 In the main interface, press the Up/Down arrow key to switch the
parameter focus to the "Slew" line.
 Enter a value by using the numeric keys. For setting methods, refer to
the descriptions in "Parameter Setting Method".
Note: If the parameter focus is on the "Slew" line, press the Left/Right
arrow key or rotate the knob to set the value for each step.
(5) Set V_Sampling (V)/C_Sampling (A)
After the list operation is finished, the readback value for each step in the
last cycle (that is, the last sampling value stably displayed for each step in
the last cycle) will be automatically displayed in the parameter list. In CC
mode, readback voltage (V_Sampling (V)) is displayed; in CV mode,
readback current (C_Sampling (A)) is displayed; and in CR and CP modes,
both readback voltage (V_Sampling (V)) and readback current (C_Sampling
(A)) are displayed.
4. Enable trigger
After you complete the parameter setting, turn on the trigger, and then the load
