Chapter 2 Front Panel Operations RIGOL
DL3000 User’s Guide 2-67
Set Fail_Tip
If the test is failed, you can determine whether to display the prompt message
that indicates the test failure.
(1) In the main interface, press Fail_Tip to switch the parameter focus to
"Fail_Tip".
(2) Press Fail_Tip to enable or disable the display of the prompt message. You
can also use the Left/Right arrow key or the knob to switch the on/off state.
Set Pass_Sound
If the test is passed, you can determine whether to sound the alarm for test
pass.
(1) In the main interface, press Pass_Sound to switch the parameter focus to
"Pass_Sound".
(2) Press Pass_Sound to enable or disable the alarm sound once the test is
passed. You can also use the Left/Right arrow key or the knob to switch the
on/off state.
Set Fail_Sound
If the test is failed, you can determine whether to sound the alarm for test
failure.
(1) In the main interface, press Fail_Sound to switch the parameter focus to
"Fail_Sound".
(2) Press Fail_Sound to enable or disable the alarm sound once the test is
failed. You can also use the Left/Right arrow key or the knob to switch the
on/off state.
4. Turn on the channel input
Press On/Off to turn on the channel input for the factory test function. At this
time, the actual input voltage, current, resistance, and power will be displayed in
the main interface.
WARNING
To avoid electric shock, ensure that the DUT is connected to the
input terminals of the load properly before you turn on the channel
input.
CAUTION
When the fan stops working, the channel is disabled. Then, a
message is displayed, "Fan stops running!"
5. Exit the factory test function
Press any key on the front panel of the load to exit the factory test function.
