Rigol DM3058 Programming Guide

RIGOL
Programming Guide for DM3058
IV
Measure Commands ................................................................................ 5-27
Memory Commands ................................................................................. 5-35
Output Commands .................................................................................. 5-40
Sample Commands .................................................................................. 5-42
Sense Commands .................................................................................... 5-45
System Commands .................................................................................. 5-90
Trigger Commands .................................................................................. 5-99
Chapter 6 DM3058 Compatibility Mode ................................................... 6-1
Compatible Agilent Commands ................................................................... 6-2
Incompatible Agilent Commands .............................................................. 6-13
Compatible Fluke Commands ................................................................... 6-16
Chapter 7 Application Examples .............................................................. 7-1
Example 1: Reading Statistic ...................................................................... 7-2
Example 2: Elimination of Test Impedance Error .......................................... 7-4
Example 3: dBm Measurement ................................................................... 7-6
Example 4: dB Measurement ...................................................................... 7-8
Example 5: P/F Test ................................................................................ 7-10
Example 6: Reading Hold ......................................................................... 7-12
Example 7: Store and Racall the Presetting ............................................... 7-13
Example 8: Query the Status Register ....................................................... 7-15
Example 9: Query the Error Information ................................................... 7-18
Quick Find Index A-Z ................................................................................... I
Common Command System .......................................................................... I
RIGOL DM3058 Commands ........................................................................... I
Compatible Fluke Commands ....................................................................... II
Compatible Agilent Command ..................................................................... III

Rigol DM3058 Specifications

General

Diode test	Yes
Product type	Digital multimeter
Frequency range	0.02 - 1000 kHz
AC current range	0.02 - 10 A
AC voltage range	0.2 - 750 V
DC current range	0.0002 - 10 A
DC voltage range	0.2 - 1000 V
Resistance range	200 - 100000000 Ω
Capacitance range	2 - 10000000 nF
Measuring category	CAT III 300V
Basic accuracy (frequency)	0.01 + 0.003
Basic accuracy (DC current)	0.055 + 0.005
Basic accuracy (DC voltage)	0.015 + 0.003
Basic accuracy (resistance)	0.020 + 0.003
Basic accuracy (capacitance)	1 + 0.5
Display digits	5.5 digits
Display size (HxV)	256 x 64 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	107 mm
Width	231.6 mm
Height	290.5 mm
Weight	2500 g
