Power source

220 V

±10%

230 V

±10% (max. 250 V

)

Maximum input power 650 VA

Interface

USB DEVICE 1

USB HOST 2 (1 for front panel and 1 for rear panel)

LAN 1

Digital IO

1 (optional for DP932U; not available for

DP932E)

Environmental Conditions

Environmental conditions

Cooling Method Fan cooling

Operating Temperature 0°C to +40°C

Storage Temperature -40°C to +60°C

Humidity 5% to 80% relative humidity

Altitude Below 1500 meters

IP Rating IP20

Pollution Degree PD2

Overvoltage Categories OVC II

Operating Environment

For indoor use only and non-operating in

humid environment.

Warranty and Calibration Interval

Warranty and calibration interval

Warranty 3 years (excluding the accessories)

Specifications
