User’s Guide for DS1000CA Series
Page 3 for Time Measurements
Figure 2-108
Table 2-74 The Time Measurement menu
Menu Settings Comments
Delay1→2
Measure the signals delay between
two channels at the rising edge.
Delay1→2
Measure the signals delay between
two channels at the falling edge.
NOTE: The results of the automatic measurements will be displayed on the bottom
of the screen. Maximum 3 results could be displayed at the same time. When there is
no room, the next new measurement result will make the previous results moving
left out of screen.
