RIGOL
1-12 Copyright ©1998-2008 RIGOL Technologies, Inc.
User’s Guide for DS1000CA Series
Vertical offset back to 0 shortcut key
Turn the
knob to change the vertical display position of
channel and press the
knob to set the vertical display position
back to 0 as a shortcut key, this is especially helpful when the trace position is
far out of the screen and want it to get back to the screen center immediately.
2. Change the vertical setup and notice that each change affects the
status bar differently.
z Change the vertical sensitivity with the
knob and notice the change
in the status bar.
z Press CH1 to turn on Channel 1.
z A soft button menu appears on the display (or remains on if it was already
turned on).
z Toggle the soft buttons and notice the changes in the status bar. Channel 1 and
2 have a vernier soft button that allows the
knob to change the
vertical step size in smaller increments. To press Volts/Div soft button to change
the step size into Fine or Coarse status.
z Press OFF button to turn off the channel.
Coarse/Fine Shortcut key
The Coarse/Fine vertical control can be set by simply pressing the vertical
knob.
