RIGOL
Copyright ©1998-2008 RIGOL Technologies, Inc.
User’s Guide for DS1000CA Series
General-Purpose Oscilloscopes
RIGOL DS1000CA-Series digital oscilloscopes offer exceptional waveform
viewing and measurements in a compact, lightweight package. The DS1000CA
series is ideal for production test, field service, research, design, education and
training involving applications of analog circuit tests and troubleshooting.
Product features:
z Dual Channel, Bandwidth:
300MHz (DS1302CA)
200MHz (DS1202CA)
100MHz (DS1102CA
60MHz (DS1062CA)
z Color TFT LCD, 320×234 pixels resolution.
z USB storage and printing supports, firmware upgrade via USB interface.
z Adjustable waveform intensity, more effective waveform viewing.
z One-touch automatic setup, ease of use (AUTO).
z 10 Waveforms, 10 setups, supports CSV and bitmap format.
z Delayed Scan Function, easy to give attention to both details and overview of a
waveform.
z 20 Automatic measurements.
z Automatic cursor tracking measurements.
z Waveform recorder, record and replay dynamic waveforms.
z User selectable fast offset calibration.
z Built-in FFT function, Frequency Counter.
z D i g i t a l f i l t e r s , i n c l u d e s L P F, H PF, B P F, B R F.
z Pass/Fail Function, optically isolated Pass/Fail output.
z Add, Subtract and Multiply Mathematic Functions.
z Advanced trigger types include: Edge, Video, Pulse width, Slope, Alternative.
z Adjustable trigger sensitivity.
z Multiple Language User Interface.
z Pop-up menu makes it easy to read and easy to use.
z Built-in Chinese and English help system.
z Easy-to-use file system supports Chinese & English characters file name input.
