RIGOL 12 Store and Recall
12-20 DS6000 User’s Guide
AuxOutput OFF
Waveform Recording
Mode OFF
Record
End Frame 3998
Operate OFF
Interval 100 ns
Max End Frame 3998
Playback
Operate OFF
Play Mode Single
Interval 100 ns
Start Frame 1
Analyze
Analysis Mode Trace
Source CH1
Trace Mode Current Frame
Current Frame 1
Template Display ON
System Setting
Vertical Expansion Ground
Screen Saver Default
Screen Saver Time OFF
External Trigger
Impedance
1 MΩ
Aux Output TrigOut
Reference Clock ClockOutput
Math Operation Setting (MATHOperation)
Operate OFF
A+B
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 2 V
A-B
Source A CH1
