Rigol DS6000 Series User Manual

12 Store and Recall RIGOL
DS6000 User’s Guide 12-21
Source B CH1
Invert OFF
Vertical Scale 2 V
A×B
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 2 U
A÷B
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 2 U
FFT
Source CH1
Window Function Rectangle
Display Split
Scale dB
Vertical Scale 20 dBV
Horizontal Scale 1.25 MHz/div
FFT Sample Rate 50 MSa/s
Anti-Aliasing OFF
Logic Operation
Expression AND
Source A CH1
Source B CH1
Invert OFF
Vertical Scale 1 U
Threshold A 0 V
Threshold B 0 V
Advanced Operation
Expression OFF
Expression CH1+CH2
Invert OFF
Vertical Scale 2 V
Protocol Decoding (MATH

BUS1/BUS2)
