RIGOL 5 To Trigger the Oscilloscope
5-10 DS6000 User’s Guide
Pulse Trigger
Trigger on positive or negative pulse with specified width.
Trigger Type:
Press Type to select "Pulse". At this point, the trigger setting information as shown
in the figure below is displayed at the upper-right corner of the screen.
Source Selection:
Press Source to select CH1-CH4 or EXT as the Trigger Source. The current trigger
source is displayed at the upper-right corner of the screen.
Note: Select channel with signal input as trigger source to obtain stable trigger.
Pulse Condition:
Press When to select the desired pulse condition.
: trigger when the positive pulse width of the input signal is greater than
the specified Pulse Width.
: trigger when the positive pulse width of the input signal is lower than the
specified Pulse Width.
: trigger when the positive pulse width of the input signal is greater than
the specified Lower Limit of Pulse Width and lower than the Upper Limit of Pulse
Width.
: trigger when the negative pulse width of the input signal is greater than
the specified Pulse Width.
: trigger when the negative pulse width of the input signal is lower than
the specified Pulse Width.
: trigger when the negative pulse width of the input signal is greater than
the specified Lower Limit of Pulse Width and lower than the Upper Limit of Pulse
Width.
