RIGOL 13 System Function Setting
13-6 DS6000 User’s Guide
USB Device
This oscilloscope can communicate with a PC or PictBridge printer via the USB
DEVICE interface on the rear panel. You need to set the oscilloscope to make it
match with different device types.
Press UTIL  IO Setting  USB Device and use to select the desired device
type.
 Computer: under this type, the oscilloscope can communicate with a PC.
 PictBridge: under this type, the oscilloscope can communicate with a PictBridge
printer.
To Set the GPIB Address
When using the GPIB method to control the oscilloscope, you need to use the
USB-GPIB interface converter (need to order separately) to extend a GPIB interface
for the oscilloscope.
To set the GPIB address, press UTIL  IO Setting  GPIB and use to input
the desired address. The default is 1 and the range available is from 1 to 30.
