1 Quick Start RIGOL
DS6000 User’s Guide 1-35
Built-in Help System
The help system of this oscilloscope provides instructions for all the function keys
(include the menu keys) on the front panel. Press HELP to open the help interface
and press again to close the interface. The help interface mainly consists of two parts.
The left part is "Help Options". You can rotate the knob
to select "To Index"
under "Button" or "To Button" under "Index", and then press it down to select the
options. The right part is "Help Display Area".
Figure 1-16 Help Information
Button:
The default mode. In this mode, you can directly press the keys or menu keys
(except the power key
, the multifunction knob and menu page up/down key
/ ) on the front panel or rotate the multifunction knob to select the desired
key and press the knob to get the corresponding help information of that key in the
"Help Display Area". Besides, you can rotate the navigation knob
to quickly
select " WaveFunder" and acquire the help information of the navigation knob. You
can use
to select "To Index" and then press the knob to switch to Index mode.
Index:
In this mode, use
to select the item that needs to get help (for example, "Band
Help Options Help Display Area
